AMGC41, Split Flow Hydraulic Manifold with Gauges and Frame, For Single-Acting Cylinders
Item ID: AMGC41
$3,532.83
Free ShippingEst. Ship date is Fri, NovĀ 6th 2026
Product Specifications
Maximum Operating Pressure (bar)700
Maximum Operating Pressure (psi)10000
Weight (lbs)23.8
Available - Built to Order
About this Product
Features
- Offers ease of portability and convenience with an ergonomic robust design, ready for use.
- Enerpac's CR400 female couplers on all ports allow the manifold to be quickly connected to up to 4 cylinders.
- 4 x Glycerine filled, 10,000 psi (700 bar) gauges allow operators to work safely.
- Protected by a robust protection frame.
Units:
Maximum Operating Pressure (bar)700
Maximum Operating Pressure (psi)10000
Weight (lbs)23.8
Weight (kg)10,6
Product TypeSplit Flow Manifold Assembly
Cylinder CompatibilitySingle-Acting Cylinders
Number of Inlet Ports1
Number of Outlet Ports4
Number of Regulated Outlet Ports4
