ATP1500, High Pressure Hydraulic Air Tensioning Pump, 21,750 psi
Item ID: ATP1500
$8,796.89
Free ShippingEst. Ship date is Thu, Oct 22nd 2026
Product Specifications
Maximum Flow at Rated Pressure4 in3/min
Output Flow Rate at 21750 psi (in3/min)4
Maximum Flow at Rated Pressure4 in3/min
Available - Backorder
About this Product
Features
- General purpose, high pressure air driven pump unit for products requiring up to 21,750 psi hydraulic pressure
- Compact, lightweight, rugged steel frame for protection and easy handling
- Prelubricated pump element, does not require an airline lubricator
- Easily adjustable output pressure control
- Integrated and protected easy to read glycerin filled gauge
- Safety relief valve limits output pressure
Units:
Maximum Operating Pressure (psi)21750
Reservoir Capacity (in3)231
Usable Oil Capacity (in3)231
Usable Oil Capacity (gal)1
Maximum Flow at Rated Pressure4 in3/min
Output Flow Rate at 0 psi (in3/min) 26
Output Flow Rate at 21750 psi (in3/min)4
Power SourceAir
Air Pressure Range (psi)80 - 90
Air Consumption (scfm)70
Sound Level (dBa)70
Weight (lbs)65
