FF120, Mechanical Flange Facing Tool
Item ID: FF120
$9,874.96
Free ShippingEst. Ship date is Tue, Nov 17th 2026
Product Specifications
Weight (lbs)15
Weight (kg)6,8
Product TypeFlange Facing Tool
Available - Backorder
About this Product
Features
- Refacing made easy - hand-operated machine tool can be set up anywhere without the need for air, electric or hydraulic power support
- Lightweight and portable - easily transported to remote locations for increased productivity
- Adjustable cutting range for flange diameters between 1-12 inches [25,4-304,8 mm]
- Interchangeable collets for ID mounting range from 1-6 inches allowing the user to work on many different flanges with minimal time between set-ups
- Interchangeable lead screws suitable for refacing damaged raised-face (RF) or flat-face (FF) joint flanges
- Tool body with expanding collets centers itself providing real concentric operation
- Accessory Kit FF120FSF is included as standard and provides a fine thread feed screw, 1/2" - 20 UNF, and delivers a Ra of: 60-100 μin (3,2 - 6,3)
Units:
Weight (lbs)15
Weight (kg)6,8
Product TypeFlange Facing Tool
Average Roughness (Ra) (μin)125 - 500
Average Roughness (Ra) (μm)3,2 - 12,5
Internal Pipe Mounting Diameter Range (in)1,0 - 6,0
Internal Pipe Mounting Diameter Range (mm)25,4 - 152,4
Pipe Flange Cutting Diameter Range (in)1,0 - 12,0
Pipe Flange Cutting Diameter Range (mm)25,4 - 304,8
