RC606A, 60 ton (533,8 kN) Capacity, 6 in (152,4 mm) Stroke, Single-Acting, Center Hole Hydraulic Cylinder
Item ID: RC606A
Product Description
Simplex RC Series Hollow Plunger Hydraulic Cylinders offer the versatility needed to take on a wide range of applications. The hollow plunger design allows bars or rods to be pulled through the inside bore to enable pulling and pushing applications - ideal for tensioning cables, bolts, and pulling sleeves or bearings.
Inside the cylinder is a high-strength return spring for plunger retraction and stop rings for blow out protection. The cylinder exterior is finished with an enamel coating to extend cylinder life, and a wiper protects the inner cylinder assembly from dirt, moisture, and other contaminants.
Product Specifications
About this Product
Simplex RC Series Hollow Plunger Hydraulic Cylinders offer the versatility needed to take on a wide range of applications. The hollow plunger design allows bars or rods to be pulled through the inside bore to enable pulling and pushing applications - ideal for tensioning cables, bolts, and pulling sleeves or bearings.
Inside the cylinder is a high-strength return spring for plunger retraction and stop rings for blow out protection. The cylinder exterior is finished with an enamel coating to extend cylinder life, and a wiper protects the inner cylinder assembly from dirt, moisture, and other contaminants.
Features
- Induction hardened piston rod for added strength eliminates the need for a saddle.
- Collar threads for easy fixing of components.
- Hollow plunger design allows for both push & pull forces.
- Large center hole for greater flexibility.
- Heavy duty spring delivers fast and full retraction
- Stop rings prevent piston blow-out
- Wiper protects inner cylinder from dirt.
- Meets ANSI/ASME B30.1 Safety Standards
- Load tested under 125% of the nominal capacity
- For working pressures up to 10,000 psi (700 bar)
80%
Think Safety
Manufacturer's rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
